Product Details:
|
| Product Name: | Color Steel EPS Sandwich Panel | Exterior Finishing: | PPGI, Stainless Steel, Galvanized Steel Sheet |
|---|---|---|---|
| Core Material: | EPS Foam | Thickness: | 50mm, 100mm, 125mm, 150mm, 200mm... |
| Width: | 950mm / 1150mm | Length: | No Limited, But It's Better No Longer Than 12m For Transport Limited |
| EPS Density: | 8kg/m³，10kg/m³，12kg/m³，14kg/m³，16kg/m³，18kg/m³，20kg/m³ | Color: | Sea Blue, Sky Blue, Off White, Ivory White, Lotus Green, Bright Red, Or Customized Color |
| High Light: | Fire Retardant EPS Sandwich Panel,Clean Room EPS Sandwich Panel,EPS Clean Room Wall Panel |
||
Fire Retardant EPS Sandwich Panel Use For Clean Room Wall Panel
EPS sandwich panel ( Polystyrene sandwich panel) is a new type of insulation panel which made of bothsides of prepainted galvanized steel and inner layer of polystyrene fame. Processing by computer-controlled color steel shapingmaching and coyered with high-strength adhensive.
EPS Sandwich Panel Specificatoin:
| Panel Thickness | Wall Panel | 50mm, 75mm, 100mm, 125mm, 150mm, 200mm |
| Roof panel | 50mm, 75mm, 100mm, 125mm, 150mm | |
| Panel width | Wall Panel | 950mm or 1150mm |
| Roof panel | 960mm or 1050mm | |
| Panel Length | Wall / Roof | no limited, but it's better no longer than 12m for transport limit. |
| External steel thickness | 0.286mm, 0.326mm, 0376mm, 0.426mm, 0.476mm, 0.5mm, 0.6mm, 0.7mm, 0.8mm, 1.0mm | |
| EPS foam density | 8kg/m³, 10kg/m³, 12kg/m³, 14kg/m³, 16kg/m³, 18kg/m³, 20kg/m³ |
EPS Sandwich Panel Characteristic:
1. Light weight. Time-saving and labor-saving for installation
2. High strength
3. Low cost
4. Water proof
5. Easy to install and easy to clean
6. Good heat insulation performance. Thermal conductivity=0.032W/m.K
7. Sound proof
8. Moisture proof
EPS Sandwich Panel Applications:
1. Prefabricated House
2. Container house
3. Clean room
4. steel structure warehouse / workshop
5. Hospital
6. Building internal partation
